�Positioners / two-axis �Positioners / five-axis DKP HW KP5-V2S2V DKP500-2 HW DKP750-2 HW KP5-V2S2V500 KP5-V2S2V600 KP5-V2S2V1000 Rated payload 500 kg 750 kg Rated payload per side 500 kg 600 kg 1,000 kg Installation position Boden Boden Max. tool radius 600 mm 750 mm 600 mm Loading height 850 mm 850 mm (in steps of 200 mm) to 1,000 mm to 1,000 mm Tilting range ±90° ±90° Installation position Floor Floor Floor Hollow shaft Ø 60 mm 60 mm Swivel range ±185° ±185° ±185° Loading height 700 mm 635 mm 700 mm KP2-HV KP5-V2H2V HW KP2-HV500 KP5-V2H2V500 HW KP5-V2H2V750 HW Rated payload 500 kg Rated payload per side 500 kg 750 kg Installation position Floor, ceiling, wall, angle Max. tool radius 400 mm 400 mm Loading height 500 mm Installation position Floor Floor Tilting range ±135° Tilting range 0° / 90° 0° / 90° Loading height 863 mm 863 mm Hollow shaft Ø 60 mm 60 mm �Positioners / three-axis KP3-V2H KP3-V2H500-2 KP3-V2H750-2 KP3-V2H1000-2 KP3-V2H1500-2 Rated payload per side 500 kg 750 kg 1,000 kg 1,500 kg Distance between face plates 1,600 mm 1,600 mm 1,600 mm 1,600 mm (in steps of 200 mm) to 3,000 mm to 3,000 mm to 3,000 mm to 3,000 mm Max. tool radius 600 mm 600 mm 600 mm 600 mmm (in steps of 200 mm) to 1,000 mm to 1,000 mm to 1,000 mm to 1,000 mm Installation position Floor Floor Floor Floor Loading height 835 mm / 950 mm 835 mm / 950 mm 835 mm / 950 mm 835 mm / 950 mm Counterbearing hollow shaft Ø 68 mm 68 mm 68 mm 68 mm KP3-H2H KP3-H2H500 KP3-H2H750 KP3-H2H1000 Rated payload per side 500 kg 750 kg 1,000 kg Distance between face plates 1,600 mm 2,000 mm 2,000 mm (in steps of 400 mm) to 4,400 mm to 4,400 mm to 4,400 mm Max. tool radius 600 mm 600 mm 600 mm (in steps of 100 mm) to 800 mm to 800 mm Installation position Floor Floor Floor Loading height 1,019 mm 1,019 mm 1,019 mm Counterbearing hollow shaft Ø 68 mm 68 mm 68 mm KP3-V2MD KP3-V2MD2000 Rated payload per side 2,000 kg Installation position Floor Loading height 880 mm Hollow shaft Ø 139 mm Product portfolio_Postitioners 092_093
